BlueSphere

Created by Mark Lindon

Frontend (Next.js) — Quick Start

cd frontend/ocean-ui
cp .env.local.example .env.local
# edit NEXT_PUBLIC_API_BASE and add a Mapbox token
npm install
npm run dev

Tile Server

cd tileserver
docker build -t tileserver .
mkdir -p tiles && # put your static tiles here
docker run --rm -p 8080:80 -v $PWD/tiles:/usr/share/nginx/html/tiles tileserver
# Visit http://localhost:8080/tiles/{z}/{x}/{y}.mvt

GitHub Actions (Nightly Ingestion)

• Add repository secrets: POSTGRES_DB, POSTGRES_USER, POSTGRES_PASSWORD, POSTGRES_HOST, POSTGRES_PORT.
• Manually trigger via Actions → Nightly Ingestion → Run workflow, or wait for the daily schedule.

Project Docs

• docs/ocean_prd.md — Product Requirements
• docs/architecture.md — Architecture
• docs/VERSIONING.md — Versioning policy
• docs/RELEASES.md — Release workflow
• docs/SETUP_GITHUB.md — GitHub setup steps
• CHANGELOG.md — Version history
• CONTRIBUTING.md — Contribution guide
• CODE_OF_CONDUCT.md — Community standards
• SECURITY.md — Security policy
• LICENSE — MIT

Smart Auto-Update

• Daily ingestion runs via GitHub Actions (.github/workflows/daily-smart-ingestion.yml).
• Incremental fetch, basic retry, and health checks planned.
• Add DB connection secrets under Settings → Secrets and variables → Actions.

Data Freshness Panel

• Frontend shows green/yellow/red badges per dataset based on latest successful ingestion.
• Backend endpoint: GET /status aggregates job_run + dataset.cadence.
• Heuristics: hourly ≤6h (green), daily ≤36h (green), monthly ≤45 days (green). Adjust as needed.

Environmental Mission

BlueSphere is more than data: it’s a climate action enabler.

• Reveals warming trends, heatwaves, sea level rise.
• Explains drivers (GHGs, stratification, circulation changes).
• Shows impacts (coral reefs, fisheries, extreme events).
• Supports solutions (mitigation, adaptation, policy, monitoring).

Vision: Use open ocean data to shape a brighter future and help fix the planet.

Pitch Deck

See assets/pitch/BlueSphere_Pitch.pptx and assets/pitch/BlueSphere_Pitch.pdf for a full presentation deck.

Presentation with Charts

See assets/pitch/BlueSphere_Pitch_WithCharts.pptx for the full deck including charts on SST trends, CO₂, heatwaves, sea level rise, and projections.

PRD Versions

• docs/ocean_prd.md — Clean developer-focused PRD (Markdown)
• assets/docs/BlueSphere_PRD_Clean.pdf — Clean PRD as PDF (ready to share)
• assets/pitch/BlueSphere_Pitch_WithCharts.pptx — Stakeholder-ready pitch deck with visuals

📑 Documentation Tracks

🔧 Clean (for developers)

• docs/ocean_prd.md — detailed PRD (Markdown)
• assets/docs/BlueSphere_PRD_Clean.pdf — clean PRD (PDF)

🎤 Pitch-Ready (for stakeholders)

• assets/pitch/BlueSphere_Pitch_WithCharts.pptx — presentation deck with visuals
• assets/pitch/BlueSphere_Pitch.pdf — exported PDF version (optional)

📝 Executive Summary

• assets/docs/BlueSphere_Summary.md — 1-page executive summary (Markdown)
• assets/docs/BlueSphere_Summary.pdf — 1-page executive summary (PDF)

Repo Map

• See docs/INSTRUCTIONS_CLAUDE_CODE.md for step-by-step GitHub publishing.

• Quick start publishing: docs/INSTRUCTIONS_CLAUDE_CODE.md or run scripts/publish_to_github.sh after editing USER/REPO.

• Release drafting: use docs/RELEASE_NOTES_TEMPLATE.md as a base for GitHub releases.

Business & Vision Docs

• docs/BRD.md — Business requirements & outcomes
• docs/VISION.md — Vision statement / manifesto
• docs/TESTING.md — QA strategy with sample test cases

Website Content (Descriptors + Copy)

• website/ — Markdown descriptors for pages (Home, Impact, Marine Life, Education, FAQ, Get Involved, Contact)

Website (Next.js) — Content-Driven

We ship a separate bluesphere-site that renders Markdown pages from /website.

cd frontend/bluesphere-site
npm install
npm run dev  # opens http://localhost:4000

Playwright E2E tests

npm run build && npm start &
npm run test:e2e

CI runs in .github/workflows/ci-node.yml.

Chatbot & FAQ Search

• Phase 1: client-side Chatbot with friendly answers seeded from FAQ; lives in the corner on all pages.
• Phase 2: API stub at frontend/bluesphere-site/pages/api/chatbot.ts ready to wire to an LLM provider.
• FAQ page (/faq) includes search and quick topic filters.

Design System & Branding

• Basic design system in frontend/bluesphere-site/components/DesignSystem.tsx
• Placeholder logo at frontend/bluesphere-site/public/logo.svg (used as favicon too).

Stories & Smarter Chatbot

• New Stories section (/stories) with long-form explainers (El Niño, Marine Heatwaves, Coral Bleaching).
• Chatbot now performs FAQ retrieval by parsing website/faq.md via /api/faq.
• Keep adding Q&A pairs in website/faq.md — the chatbot gets smarter automatically.

Multi‑Agent Kickoff

• Runbook: docs/AGENT_RUNBOOK.md
• Plan: tasks/agent_plan.yaml
• Backlog: tasks/todo_backlog.md
• One‑liner prompt for Claude: docs/CLAUDE_ONE_LINER.txt

• Bootstrap script: scripts/bootstrap_agents.sh

• Bulk issues: tasks/issues_import.json can be uploaded to GitHub via importer.

Bulk-create GitHub Issues

We provide a JSONL seed and a helper script (requires gh + jq):

./scripts/import_issues.sh Twick1234 BlueSphere

This reads tasks/issues_seed.jsonl and creates labeled issues automatically.

Issue Templates

Pre-configured GitHub issue templates are available under .github/ISSUE_TEMPLATE/:

• Bug reports (bug_report.md)
• Feature requests (feature_request.md)
• Documentation updates (documentation.md)

Pull Request Template

A default PR template is provided under .github/PULL_REQUEST_TEMPLATE/pull_request_template.md. Contributors should fill in description, related issues, type, tests, and checklist.

Code Owners

We define ownership in .github/CODEOWNERS. Adjust usernames/teams so PRs auto-request reviews.

Contributing

See CONTRIBUTING.md for setup, branching, commit style, and PR process.

Contributing

Please read CONTRIBUTING.md for setup, branching, commit style, tests, and PR process. We use issue/PR templates and CODEOWNERS for smooth collaboration.

Governance & Policies

• Code of Conduct: see CODE_OF_CONDUCT.md
• Security policy: see SECURITY.md for responsible disclosure process

Attribution

Created by Mark Lindon — Founder & Lead Author of BlueSphere.

SPDX Licensing

We include SPDX headers in source files for clarity and tooling compatibility. Use the snippet in docs/SPDX_HEADER.txt:

// SPDX-License-Identifier: MIT
// SPDX-FileCopyrightText: 2024–2025 Mark Lindon — BlueSphere

Third‑Party Licenses

We include a LICENSES/THIRD_PARTY.md scaffold and scripts to generate detailed lists:

• JS/TS: scripts/render_js_licenses.py (requires license-checker)
• Python: scripts/render_py_licenses.py (requires pip-licenses)

Pre‑commit

Install and enable pre-commit to enforce SPDX headers:

pip install pre-commit
pre-commit install
pre-commit run --all-files

This runs basic hygiene checks and ensures new files include SPDX headers.

Release Compliance

On every GitHub Release (published), CI will generate third‑party license files and attach them to the release:

• Workflow: .github/workflows/release-attach-licenses.yml
• Outputs: LICENSES/THIRD_PARTY_JS.md, LICENSES/THIRD_PARTY_PY.md, and JSON manifests

Automated Releases & Dependencies

• Release Drafter keeps a live draft release based on merged PR labels (.github/release-drafter.yml + workflow).
• Dependabot opens weekly PRs for npm, pip, Docker, and GitHub Actions updates (.github/dependabot.yml).
• Snyk Scan workflow runs security tests on pushes/PRs if SNYK_TOKEN secret is set (optional).

Discussions

GitHub Discussions are enabled with categories:

• Q&A — for help and support
• Ideas — to propose and discuss new features
• Announcements — for project updates Configuration: .github/discussions.yml

Discussions (Community)

• Enable categories with one click via Actions → Setup Discussions (workflow_dispatch), or run:

  ./scripts/setup_discussions.sh Twick1234 BlueSphere


• Templates live in .github/DISCUSSION_TEMPLATE/ for Q&A, Ideas, and Announcements.
• Discussions: https://github.com/Twick1234/BlueSphere/discussions

Public Roadmap

See docs/ROADMAP.md. The Roadmap content is also posted to the pinned discussion automatically by scripts/create_pinned_discussions.sh.

Website Deployment (GitHub Pages)

A workflow deploys the static export of the site to GitHub Pages on each push to main:

• Workflow: .github/workflows/deploy-pages.yml
• After the first run, enable Pages in GitHub Settings → Pages → Source: GitHub Actions. Your site will be available at: https://Twick1234.github.io/BlueSphere/

Backend API (FastAPI)

• docker compose up then browse http://localhost:8000/docs
• Endpoints: /status, /stations, /grid/sst, /currents (stubs)

Ingestion

• See ingestion/ingest_ndbc.py and ingestion/ingest_ersst.py (stubs). Copy .env.example to .env.

Map UI

• cd frontend/ocean-ui && npm install && npm run dev (http://localhost:3000). Fetches API /status for now.

Policies

• PRIVACY.md and TERMS.md added.

Branch Protection

• Apply protection with: ./scripts/protect_main.sh Twick1234 BlueSphere

Monitoring

• Scheduled uptime checks in .github/workflows/uptime.yml (Pages + placeholder API).

Data docs

• docs/DATA_DICTIONARY.md and docs/DATA_LICENSES.md.

Modeling

• docs/MODEL_CARD_TEMPLATE.md and docs/MODEL_EVAL_PLAN.md.

Tiles & Map Layers

• API now serves placeholder tiles:
  • http://localhost:8000/tiles/sst/{z}/{x}/{y}.png
  • http://localhost:8000/tiles/currents/{z}/{x}/{y}.png
• UI map page: frontend/ocean-ui/pages/map.tsx (Leaflet)
• Start API (docker compose up) then run UI (npm run dev) and open http://localhost:3000/map
• Replace placeholder tile renderers with real SST/currents imagery when ready.

Data-Backed Tiles (SST & Currents)

To precompute SST tiles from an ERSST NetCDF:

# Install data libs inside the API image or local env first
pip install -r backend/requirements.txt

# Build SST PNG tiles at zooms 0..2
python ingestion/make_sst_tiles.py /path/to/ersst.v5.YYYYMM.nc 0 2

Generate synthetic currents vector tiles (MVT):

pip install -r backend/requirements.txt
python ingestion/make_currents_mvt.py 0 2

Start API and UI:

docker compose up
cd frontend/ocean-ui && npm install && npm run dev
# Open http://localhost:3000/map

The map loads SST PNG tiles and a VectorGrid overlay that fetches MVT currents.

ERDDAP Adapter

Use ingestion/erddap_adapter.py to pull recent slices from ERDDAP (tabledap/griddap). Set ERDDAP_BASE and dataset/env vars, then call from ingestion pipelines.

Daily Tiles Refresh (CI)

A scheduled workflow (.github/workflows/daily-tiles-refresh.yml) regenerates vector (synthetic) currents and, if ERSST_URL secret is set, builds SST PNG tiles. Optionally commits the refreshed cache to main.

Database (Postgres)

• Compose includes db (Postgres 16) and adminer for quick browsing on http://localhost:8080
• Create tables:

  docker compose up -d db adminer
  pip install -r backend/requirements.txt
  python backend/create_tables.py


• API will read stations/status from DB. Ingestion scripts can upsert rows.

Ingestion → DB

• ingestion/ingest_ndbc.py and ingestion/ingest_ersst.py now include DB helpers to upsert observations and record JobRun results.
• Copy .env.example to .env and set POSTGRES_* as needed.

ERDDAP Sample

• Pull a small slice and write to parquet:

  pip install -r backend/requirements.txt
  python ingestion/erddap_to_parquet.py


NDBC Realtime2 Ingestion

We now parse NDBC realtime2 text files (e.g., data/realtime2/41001.txt) extracting WTMP (water temperature, °C).
Parser: ingestion/ndbc_parser.py → used by ingestion/ingest_ndbc.py.

End-to-end test

# Start DB + API
docker compose up -d db adminer
pip install -r backend/requirements.txt
python backend/create_tables.py
docker compose up api

# Run NDBC ingestion (example station 41001)
python ingestion/ingest_ndbc.py

# Query observations
curl 'http://localhost:8000/obs?station=41001&limit=5'

Observations API

• GET /obs — query buoy observations with filters (bbox, time, station, paging).
• GET /obs/summary — daily aggregations (count/avg/min/max) with same filters.

End-to-end tests (Playwright)

cd tests/e2e
npm install
npx playwright install --with-deps
# Start API and UI in terminals, then:
npm test

CI: Playwright E2E

A GitHub Actions workflow (.github/workflows/ci-e2e.yml) starts the API and UI, waits for readiness, and runs the E2E tests on PRs and main pushes.

Bundle Consistency

A concise overview of what’s in sync lives in docs/CONSISTENCY_REPORT.md.
We also publish it to the site at /consistency via frontend/bluesphere-site/pages/consistency.mdx.

Website Navigation & Styling

• Site-wide top nav is provided by frontend/bluesphere-site/components/Layout.tsx.
• Minimal CSS lives in frontend/bluesphere-site/styles/globals.css (works immediately).
• Optional TailwindCSS is pre-configured; to enable advanced styling locally:

  cd frontend/bluesphere-site
  npm install
  npm run dev
  # Tailwind is enabled through postcss + tailwind configs already included.


Brand

Logos and brand assets are stored in frontend/bluesphere-site/public/brand/.
See docs/BRAND_GUIDE.md for palette, typography, and usage rules.

Dark Mode & Social Previews

• Dark Mode: automatic palette + logo swap via prefers-color-scheme (see docs/DARK_MODE.md).
• Open Graph & Twitter: meta tags and images wired via components/HeadMeta.tsx and public/brand/* (see docs/SOCIAL_PREVIEW.md).

Theme Toggle

A Sun/Moon toggle in the site header lets users switch Light / Dark / System themes. See docs/THEME_TOGGLE.md.

About Page

We added an About page with our mission, environmental goals, data sources, and brand story at /about.

Data Sources

We added a Sources page (/sources) and docs/DATA_SOURCES.md describing datasets, cadence, and integration.

Data Sources

• New Sources page at /sources describes datasets, cadence, links, and license notes.
• See also docs/DATA_SOURCES.md for a deeper reference.

This site is open source. Improve this page.
